FLC-BTM020 uses the 32-bit ARM Cortex M4F MCU, base of NRF52832, together with extensive flash availability, 512kB in total.
This module enables customers to add ultra-low power wireless connectivity to their products. Customers can easily establish wireless connections with the module. It supports Bluetooth low energy (Bluetooth 5), ANT and 2.4GHz proprietary protocol stacks. It also has a NFC-A tag interface for OOB pairing.
Bluetooth low energy takes less time to establish a connection than conventional Bluetooth wireless technology and can consume approximately 1/20th of the power of Bluetooth Basic Rate. BTM020 Used in smart home, health care, smart wearable equipment, etc.
Advantage:
Ultra low power
Increased application code and data space for greater application development flexibility.
Qualified Bluetooth v4.0 stack inside.
More quickly connecting.
High quality performance.
BQB/FCC/CE.
Feature:
- BT5.0(BLE only)，up to 2Mbs
- -96dbm sensitivity, TX power -20~ 4dBm in 4dB steps
- Include ATT, GATT, SMP, L2CAP, GAP
- AES HW encryption with EasyDMA
- ANT,2.4GHz,NFC-A tag
- Cortex M4F MCU with 64KB RAM ,512KB FLASH
- 32kHz and 16MHz system clock
- 20-channel Programmable peripheral interconnect (PPI)
- 12 bits ADC
- 20 digital PIOs
- USART,SPI,I2C,QDEC, PDM
- SWD Debug interface
- Size: 16.00mm x 9.5mm (with antenna),
- Operating temperature: -40℃to +85℃
- BQB/FCC/CE
- RoHS
Application:
Smart home: heating control and lighting control
Health sensors: blood pressure, thermometer and glucose meters
Sports and fitness sensors: heart rate, runner speed and cadence, cycle speed and cadence
HID Devices: keyboards, mice,touchpads, remote controls
